Milton Roy LMI D Series Solenoid Diaphragm Metering Pump
LMI D Series solenoid-driven diaphragm metering pumps: flow up to 90 L/h, pressure up to 18 bar (brochure headline; see model table). Manual/auto speed control, stroke adjustable while running, ±2% steady-state accuracy (10–100% flow).
Max flow
up to 90 L/h (; inside D-14/74/94 max. 90 L/h)
Max pressure
up to 18 bar (; inside type no. max. pressure see, single kg/cm²)
Turndown / accuracy
±2% (10–100% flow range)
Wetted materials
—
Protection
—
Power
AC 230V 50Hz single-phase; power consumption approx. 100 W; "9" series can automatic control (e.g. 4–20 mA)
Features
- Flow up to 90 L/h; pressure up to 18 bar (brochure headline)
- Solenoid-driven mechanical diaphragm; fewer moving parts
- Manual/auto speed control; stroke adjustable while running
- PTFE-faced Hypalon composite diaphragm
- 0–100% capacity adjustability running or stopped
- ±2% steady-state accuracy (10–100% of rated flow); max suction lift 1.5 mWC
Specifications
| Flow | up to 90 L/h (; inside D-14/74/94 max. 90 L/h) |
| Max pressure | up to 18 bar (; inside type no. max. pressure see, single kg/cm²) |
| Drive | solenoid drive mechanical diaphragm |
| Accuracy | ±2% (10–100% flow range) |
| Max suction lift | 1.5 m water column |
| Power | AC 230V 50Hz single-phase; power consumption approx. 100 W; "9" series can automatic control (e.g. 4–20 mA) |
| Liquid ends | PP / PVC / PVDF; valve ball ceramic; diaphragm TEFLON FACED HYPALON |
| Brand | m LMI / Milton Roy LMI |
Applications
Materials & media
Ask for wetted-parts details or check the brochure.
Common chemicals: NaOCl, acids, alkalis, polymers — confirm compatibility when inquiring.
Controls & communication
| Power | AC 230V 50Hz single-phase; power consumption approx. 100 W; "9" series can automatic control (e.g. 4–20 mA) |
Models & specs
| Model | Flow | Pressure | Notes | |
| D-11 / D-71 / D-91 | 0.1–12 L/h | 9 kg/cm² | connection 1/2"×3/8"; weight approx. 8.5 kg (plastic) | |
| D-12 / D-72 / D-92 | 0.15–17 L/h | 7 kg/cm² | connection 1/2"×3/8" | |
| D-13 / D-73 / D-93 | 0.25–35 L/h | 4 kg/cm² | connection 1/2"×3/8" | |
| D-14 / D-74 / D-94 | 0.6–90 L/h | 1.5 kg/cm² | connection 1/2"×3/8"; series max flow point; weight approx. 9 kg |
Dimensions & installation
Dimensional drawings available on request (CAD / PDF).
