Mechanical Diaphragm Pumps
Zhongcheng JBB Mechanical Diaphragm Metering Pump
Zhongcheng JBB mechanical diaphragm metering pump for precise chemical dosing. Catalog ~5–120 L/h, ~0.4–1.0 MPa.
Max flow
5–120 L/h
Max pressure
0.4–1.0 MPa
Turndown / accuracy
—
Wetted materials
—
Protection
—
Power
—
Features
- Heads in PVC, PTFE, SS304/316
- Flow adjustable while running; leak-free
- PTFE/rubber composite diaphragm
- Tank-mountable, easy service
- 380V / 220V / DC motor options
Specifications
| Flow range | 5–120 L/h |
| Pressure range | 0.4–1.0 MPa |
| Motor power | 60 W |
Applications
Materials & media
Ask for wetted-parts details or check the brochure.
Common chemicals: NaOCl, acids, alkalis, polymers — confirm compatibility when inquiring.
Controls & communication
Control options are listed in notes or confirmed on inquiry.
Models & specs
| Model | Flow | Pressure | Power | Notes | |
| JBB 5/1.0 | 5 L/h | 1 MPa | 60 W | ||
| JBB 10/1.0 | 10 L/h | 1 MPa | 60 W | ||
| JBB 20/1.0 | 20 L/h | 1 MPa | 60 W | ||
| JBB 30/1.0 | 30 L/h | 0.8 MPa | 60 W | ||
| JBB 40/0.8 | 40 L/h | 0.8 MPa | 60 W | type no. JBB 40/0.0, pressure 0.8 MPa | |
| JBB 60/0.6 | 60 L/h | 0.6 MPa | 60 W | ||
| JBB 80/0.5 | 80 L/h | 0.5 MPa | 60 W | ||
| JBB 100/0.5 | 100 L/h | 0.4 MPa | 60 W | rated pressure 0.4 MPa | |
| JBB 120/0.4 | 120 L/h | 0.4 MPa | 60 W |
Dimensions & installation
Dimensional drawings available on request (CAD / PDF).
