KHV-A 4~20mA Automatic Control Metering Pump (Cheon-Sei / KEMPION)
Cheon-Sei KHV1-A 4~20mA auto-control compact high-pressure metering pumps; 4 models, higher pressure with STS wet end.
Max flow
50 ml/min … 720 ml/min
Max pressure
10 / 30 kgf/cm² (PTC-FTC / STS)
Turndown / accuracy
—
Wetted materials
—
Protection
—
Power
—
Features
- Same BLDC 4~20mA auto family as KDV-A
- Four models: KHV1-A-51S/12S/32S/72S
- PTC-FTC ~10 kgf/cm²; STS up to 20–30 kgf/cm²
- 200 W motor, STS KS20K 15A flange
- Effective flow range 5–100%
Specifications
| Control signal | 4~20mA |
| Models | 4 |
| Brand | KEMPION / Cheon-Sei |
Applications
Materials & media
Ask for wetted-parts details or check the brochure.
Common chemicals: NaOCl, acids, alkalis, polymers — confirm compatibility when inquiring.
Controls & communication
| Control signal | 4~20mA |
Models & specs
| Model | Flow | Pressure | SPM | Power | Tube | Notes | |
| KHV1-A-51S | 50 ml/min | 10 / 30 kgf/cm² (PTC-FTC / STS) | 58 | 200 W | STS KS20K 15A | stroke 10mm | |
| KHV1-A-12S | 100 ml/min | 10 / 30 kgf/cm² (PTC-FTC / STS) | 116 | 200 W | STS KS20K 15A | stroke 10mm | |
| KHV1-A-32S | 360 ml/min | 10 / 25 kgf/cm² (PTC-FTC / STS) | 58 | 200 W | STS KS20K 15A | stroke 10mm | |
| KHV1-A-72S | 720 ml/min | 10 / 20 kgf/cm² (PTC-FTC / STS) | 116 | 200 W | STS KS20K 15A | stroke 10mm |
Dimensions & installation
connection sizes shown, no separate outline drawing. wetted end / hose / flange sizes per model table; KDV-A/KHV-A controller and wiring diagram included. max. pressure standard motor / material can; effective adjustment 5–100%.
