Boyu DZ-X Plunger Metering Pump
Boyu DZ-X plunger metering pump. 0–220 L/h, up to 50 MPa, ±1% accuracy, viscosity 0–800 mm²/s, temp to 450°C.
Max flow
0 – 220 L/h
Max pressure
0 – 50 MPa
Turndown / accuracy
±1%
Wetted materials
—
Protection
—
Power
—
Features
- Simple plunger design
- SS or ceramic plunger options
- Manual or automatic control
- PVC head std; 316/Ex/VFD options
Specifications
| Flow | 0 – 220 L/h |
| Pressure | 0 – 50 MPa |
| Accuracy | ±1% |
| Viscosity | 0 – 800 mm²/s |
| Temperature | 450 °C |
| Drive | three-phase or Ex-proof motor |
| Brand | Boyu |
Applications
Materials & media
Ask for wetted-parts details or check the brochure.
Common chemicals: NaOCl, acids, alkalis, polymers — confirm compatibility when inquiring.
Controls & communication
Control options are listed in notes or confirmed on inquiry.
Models & specs
| Model | Notes | |
| DZ-X | 0–220 L/h | |
| DZ-X2 | 0–440 L/h | |
| DZ-Z | 0–470 L/h | |
| DZ-D | 0–4150 L/h |
Dimensions & installation
Dimensional drawings available on request (CAD / PDF).
