NDM Series High-Efficiency Mixer
Top-mounted vertical high-efficiency mixer for homogenizing, dissolving and mixing liquids in wastewater and industrial processes; tank volumes 100-2000 L.
Max flow
—
Max pressure
—
Turndown / accuracy
—
Wetted materials
—
Protection
—
Power
380V / 220V / custom
Features
- High-pressure injection-molded blades
- Multiple blade materials for complex mixing
- Modular quick assembly, low maintenance
- Rolling bearings for low vibration and noise
- Not limited by medium viscosity or concentration
- Optional independent start and indicator module
Specifications
| Tank volume | 100 - 2000 L |
| Blade diameter | 150 - 330 mm |
| Shaft length | 600 - 1500 mm |
| Motor power | 40 W |
| Speed | 75 / 100 / 150 / 200 r/min |
| Voltage | 380V / 220V / custom |
Applications
Materials & media
| Impeller | standard PP; optional PVDF, SS304/316 (dual impeller) |
| Shaft | standard PVC; optional SS304/SS316 + PTFE etc. |
| Seal | FKM |
Common chemicals: NaOCl, acids, alkalis, polymers — confirm compatibility when inquiring.
Controls & communication
| Optional start/indicator module | — |
Models & specs
| Model | Power | Notes | |
| NDM-100L | 40 W | drum volume 100L impeller 150mm shaft length 600mm 75/100/150/200 r/min | |
| NDM-200L | 40 W | drum volume 200L impeller 220mm shaft length 700mm | |
| NDM-300L | 40 W | drum volume 300L impeller 220mm shaft length 800mm | |
| NDM-500L | 40 W | drum volume 500L impeller 280mm shaft length 800mm | |
| NDM-1000L | 40 W | drum volume 1000L impeller 330mm shaft length 1000mm | |
| NDM-1500L | 40 W | drum volume 1500L impeller 330mm shaft length 1200mm | |
| NDM-2000L | 40 W | drum volume 2000L impeller 330mm shaft length 1500mm |
Dimensions & installation
flange approx. 120×150mm, mounting 110×120mm, cutout Ø92–Ø100mm; motor high approx. 225mm; max. 10mm. voltage A:380V B:220V C: custom.
